Husqvarna 345R - Carburetor Details

Husqvarna 345R - Carburetor Details
Husqvarna 345R - Carburetor Details

Description

Husqvarna 345R

Model Year -

Carburetor Details - Parts Diagram

Ref. Img. Part No. Details
  1 Carburettor
Carburettor
HV503 28 31-16 Out of stock
Carburettor
£93.24 £77.70

  1 Carburettor
Carburettor
HV503 28 31-18 Out of stock
Carburettor
£90.12 £75.10

  2 Screw
Screw
HV503 48 05-01 Out of stock
Screw
£1.51 £1.26

  4 Diaphragm
Diaphragm
HV503 48 02-01 Out of stock
Diaphragm
£16.97 £14.14

  5 Gasket
Gasket
HV503 48 03-01 Out of stock
Gasket
£5.36 £4.47

  6 Plug Welch
Plug Welch
HV503 53 56-01 Out of stock
Plug Welch
£4.91 £4.09

  7 Nozzle Assy
Nozzle Assy
HV544 11 49-01 Out of stock
Nozzle Assy
£26.33 £21.94

  9 Pin Retaining Screw
Pin Retaining Screw
HV503 48 00-01 Out of stock
Pin Retaining Screw
£4.50 £3.75

  10 Lever
Lever
HV503 66 59-01 Out of stock
Lever
£5.47 £4.56

  11 Valve
Valve
HV503 47 97-01 Out of stock
Valve
£14.08 £11.73

  13 Screw
Screw
HV503 47 90-01 Out of stock
Screw
£1.24 £1.03

  14 Lever
Lever
HV537 01 98-01 Out of stock
Lever
£6.71 £5.59

  16 Shaft Assy
Shaft Assy
HV537 02 09-01 Out of stock
Shaft Assy
£21.68 £18.07

  17 Collar
Collar
HV503 48 19-01 Out of stock
Collar
£7.27 £6.06

  18 Lever
Lever
HV537 04 90-01 Out of stock
Lever
£5.41 £4.51

  19 Valve
Valve
HV537 02 11-01 Out of stock
Valve
£8.32 £6.93

  20 Screw
Screw
HV503 48 18-01 Out of stock
Screw
£1.24 £1.03

  21 Spring
Spring
HV537 02 10-01 Out of stock
Spring
£3.28 £2.73

  24 Strainer
Strainer
HV503 53 57-01 Out of stock
Strainer
£5.04 £4.20

  25 Screw
Screw
HV503 75 53-01 Out of stock
Screw
£1.15 £0.96

  26 Diaphragm Pump
Diaphragm Pump
HV537 02 00-01 Out of stock
Diaphragm Pump
£15.10 £12.58

  27 Gasket
Gasket
HV537 02 01-01 Out of stock
Gasket
£4.45 £3.71

  28 Cover
Cover
HV537 02 02-01 Out of stock
Cover
£23.42 £19.52

  30 Screw
Screw
HV537 02 07-01 Out of stock
Screw
£1.67 £1.39

  31 Piece
Piece
HV503 48 11-01 Out of stock
Piece
£6.17 £5.14

  34 Screw
Screw
HV503 47 92-01 Out of stock
Screw
£1.24 £1.03

  36 Limiter Cap
Limiter Cap
HV503 90 33-01 Out of stock
Limiter Cap
£4.87 £4.06

  38 Screw
Screw
HV537 27 56-01 Out of stock
Screw
£16.92 £14.10

  40 Washer
Washer
HV503 97 40-01 Out of stock
Washer
£2.23 £1.86

  41 Retainer
Retainer
HV503 90 34-01 Out of stock
Retainer
£4.74 £3.95

  42 Boot
Boot
HV537 27 42-01 Out of stock
Boot
£4.64 £3.87

  44 Screw
Screw
HV537 38 69-01 Out of stock
Screw
£1.67 £1.39

  45 Spring
Spring
HV503 48 08-01 Out of stock
Spring
£3.38 £2.82

  46 Gasket Kit
Gasket Kit
HV537 24 36-01 Out of stock
Gasket Kit
£12.47 £10.39


Description

Husqvarna 345R

Model Year -

Carburetor Details - Parts Diagram
